Uninsulated Flexible Duct
Uninsulated flexible ducts are lightweight, ribbed aluminum air ducts used in HVAC systems. They consist of a single outer layer without any insulation, making them easy to install in tight spaces. These ducts are best suited for short runs, connections, or areas where thermal insulation and soundproofing are not required.

Slide 2
Floduct PRE-Insulated Ducting System

Floduct Pre-Insulated Ducting System is a lightweight, high-performance air distribution solution designed for HVAC applications. It features a rigid PIR (polyisocyanurate) foam core factory-laminated with aluminum foil on both sides, providing excellent thermal insulation, airtightness, and moisture resistance. This advanced system ensures energy-efficient airflow, reduced heat loss, and quieter operation while being easy to fabricate, install, and maintain. Ideal for commercial, residential, and industrial environments, Floduct combines durability with superior indoor air quality and long-term cost savings.

FD-20-PIR-6035

Standard Specifications
Density 2.19 to 13.12 lb/ft³ (35 to 50 Kg/m³) ASTM D1622 / EN 13403
Service Temperature (foam only) from −4°F to 158°F (−20°C to 70°C) ASTM C177 / ASTM C411 EN 1604
Apparent Thermal Conductivity at 50°F (10°C) 0.22 BTU·inch/ft²·°F·h (0.032 W/mK) EN 12667 / ASTM C518
Water Vapour Permeability ≤ 2.0 perm·inch (2.9×10⁻¹³ g/Pa·s·m) ASTM E96 / EN 12086
Water Absorption (Liquid phase) < 0.1% (by volume) ASTM C272 / EN 12087
Resistance To Fungi Zero Growth ASTM G21
Resistance To Bacteria No Growth ASTM G22
Surface Burning Characteristics Class A ASTM E84
Surface Spread of Flame Class 0 BS 476 Part 6 and Part 7
Classification of Reaction to Fire B–s1, d0 EN 13501-1
VOC Emissions TVOC’s <0.5 mg/m²/h
Formaldehyde: <0.05 ppm Individual		 CDPH V1.2 LEED V4
  • Pre-Insulated Panels – Made of polyisocyanurate (PIR), coated with aluminum facings for thermal efficiency and durability.
  • Ductwork Components- Panels are cut, shaped, and assembled into ducts, fittings, and transitions to form a complete air distribution system.
  • Accessories & Connectors- Includes flanges, adhesives, sealants, and reinforcements profiles to ensure airtight connections and structural integrity.
  • Fire & Hygiene Compliance Features -Designed to meet industry regulations, offering low smoke emissions, fire resistance, and antimicrobial properties.
  • Application-Specific Configurations -Available in two thicknesses and finishes to suit different HVAC requirements, from commercial buildings to clean rooms.
  1. Suitable for low and medium pressure ventilation and air conditioning systems
  2. Acoustically & thermally insulated
  3. Aluminium inner and outer face
  4. M0 certified according to France national reaction to fire standard
